155
Appendix
Main Specifications
à Video
Video Processing 4:2:2 (Y/Pb/Pr), 8-bit
Number of Video
Channels
12 channels
Input Connectors
HDMI IN 1–6
HDMI type A x 6
* HDCP Supported, Multi-format Supported
SDI IN 1–6
BNC type x 6
* Conforms to SMPTE 424M (SMPTE 425M-AB), 292M
Output Connectors
HDMI OUT 1–3
HDMI type A x 3
* HDCP Supported
SDI OUT 1–3
BNC type x 3
* Conforms to SMPTE 424M (SMPTE 425M-AB), 292M
USB STREAM USB Type-C ®
Video Input Formats
HDMI IN 1–6
Frame Rate
59.94 Hz, 60 Hz 50 Hz
480/59.94i 480/59.94p 576/50i 576/50p
720/59.94p 720/50p
1080/59.94i 1080/59.94p 1080/50i 1080/50p
1080/60p 1080/25p
1080/29.97p 1080/30p 1080/23.98p 1080/24p
1080/23.98p 1080/24p VGA (640×480/60 Hz)
VGA (640×480/60 Hz) SVGA (800×600/60 Hz)
SVGA (800×600/60 Hz) XGA (1024×768/60 Hz)
XGA (1024×768/60 Hz) WXGA (1280×800/60 Hz)
WXGA (1280×800/60 Hz) SXGA (1280×1024/60 Hz)
SXGA (1280×1024/60 Hz) FWXGA (1366×768/60 Hz)
FWXGA (1366×768/60 Hz) SXGA+ (1400×1050/60 Hz)
SXGA+ (1400×1050/60 Hz) UXGA (1600×1200/60 Hz)
UXGA (1600×1200/60 Hz) WUXGA (1920×1200/60 Hz)
WUXGA (1920×1200/60 Hz)
* The refresh rate is the maximum value of each resolution.
* Conforms to CEA-861-E,VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60 Hz: Reduced blanking
* The input interlaced video signal is converted to progressive video signal by internal processing.
SDI IN 1–6
Output Format : 720p Output Format : 1080i or 1080p
Frame Rate Frame Rate
59.94 Hz, 60 Hz 50 Hz 59.94 Hz, 60 Hz 50 Hz
720/59.94p 720/50p 1080/59.94i 1080/59.94p 1080/50i
1080/60p 1080/50p
1080/29.97p 1080/30p 1080/25p
1080/23.98p 1080/24p 1080/23.98p
1080/24p
* The input interlaced video signal is converted to progressive video signal by internal processing.
