Appendix
Appendix-3
Choosing the Appropriate Paper
This section describes guidelines for choosing paper.
Paper Condition
Avoid using paper with bent corners or paper that is curled, dirty, or torn. Do not use paper that has
a rough surface or paper fiber lint, or that is especially delicate. Use of paper in any of these
conditions will not only deliver poor copies but may also cause paper jams and shorten the useful
life of the machine. Choose paper with a smooth and even surface; however, avoid coated paper or
paper with a treated surface as this may damage the drum or fusing unit.
Constituent components
Do not use coated or surface-treated papers, or paper that contains plastic or carbon. These paper
may produce harmful fumes from the heat of copying and may damage the drum.
For standard paper, choose paper with at least 80 % pulp content. Select products with less than
20 % cotton or other fiber content.
Paper size
The cassettes and MP tray support the following paper sizes.
Measurements in the table take into account a dimensional variance of ±0.7 mm for length and
width. Corner angles must be 90° ±0.2°.
MP Tray Cassette or MP Tray
B6R (128 × 182 mm) A3 (297 × 420 mm)
Postcard (100 × 148 mm) B4 (257 × 364 mm)
Return postcard (148 × 200 mm) A4 (297 × 210 mm)
Executive (7
1/4
× 10
1/2
") A4R (210 × 297 mm)
Envelope DL (110 × 220 mm) B5 (257 × 182 mm)
Envelope C5 (162 × 229 mm) B5R (182 × 257 mm)
Envelope C4 (229 × 324 mm) A5R (148 × 210 mm)
ISO B5 (176 × 250 mm) Folio (210 × 330 mm)
Comm.#10 (4
1/8
Ч 9
1/2
") 11 Ч 17"
Comm.#9 (3
7/8
Ч 8
7/8
") 8
1/2
Ч 14"
Comm.#6-3/4 (3
5/8
Ч 6
1/2
") 11 Ч 8
1/2
"
Monarch (3
7/8
Ч 7
1/2
") 8
1/2
Ч 11"
YOUKEI 2 (114 × 162 mm) 5
1/2
× 8
1/2
"
YOUKEI 4 (105 × 235 mm) 8
1/2
× 13"
Input size
(3
7/8
Ч 5
7/8
" - 11
5/8
Ч 17")
(98 Ч 148 - 297 Ч 432 mm)
8
1/2
× 13
1/2
"
8K (273 × 394 mm)
16K (273 × 197 mm)
16KR (197 × 273 mm)
