132
English
Using the WhiteBoard function
Note
● To use the WhiteBoard function, an external touch panel or mouse is required.
● When using the WhiteBoard function, select [Setup] - [Whiteboard settings], and set [Whiteboard] to [On]. (see page
71)
● When using a mouse, use click operation.
● When using an external touch panel, use touch operation.
● The following cases do not support the operation.
• When [Display orientation] is set to [Portrait] (page 86)
• When [Image rotation] is set to [180 degrees] (page 86)
Control menu
From the Control menu displayed at the bottom of the screen, click the function you want to use.
To show the Control menu, navigate to [Setup] - [Whiteboard settings], and set [Control menu]. (see page 71)
When [Control menu]: [Bottom] When [Control menu]: [Top]
■
Control menu
Input selection
WhiteBoard
Input display
Zoom
App Launcher
Volume level
control / Mute
Close
Display setting
Input selection
Switches the input source to the one you click. You can select the input sources displayed on the Control menu.
“Quick input settings” (see page 71)
Input display
Lists the selectable input sources.
WhiteBoard
Transparent mode or WhiteBoard mode is set.
WhiteBoard is started up with the pen colour clicked.
You can start it up with blue, yellow, red, or black.
Note
● The buttons are grayed out and you cannot start up WhiteBoard in the following cases:
• Several seconds after the input source is switched
● In the following cases, instead of WhiteBoard, the simple drawing function starts up:
• When USB input is active
• When the comparison mode is activated
