5.1.2 Creating a New Macro
To create a new Macro, follow the procedure below:
•
Launch the Macro Editor application.
◦
Menu → Doremi Apps → Macro Editor
•
Click on the Add button (Figure 9).
•
Input the desired name for the Macro and add comments if necessary.
•
After the Macro has been created, click on the Save button to save the created Macro.
•
To upload the the Macros to the screens available on the TMS:
◦
Click on the Upload button (Figure 9).
◦
The Macros will be uploaded to the screens.
5.1.3 Editing a Macro
Follow the procedure below to edit a selected Macro:
•
Use the arrow keys on the side of the window to scroll through the list of Macros.
•
To reset all modifications done locally:
◦
Click on the Reset button (Figure 9).
◦
The Question Window will be prompted.
◦
Click on the Yes button to reset the modifications.
•
To edit a selected Macro:
◦
Click on the desired Macro to highlight it.
◦
Click on the settings button or double click on the Macro itself (Figure 9).
◦
The Macro Settings window will be prompted allowing the user to change the name of the
macro or add any additional comments.
◦
On the Macro Settings window, the user can choose to apply the Macro to additional
servers available on the TMS server.
▪
Identify the server by the serial number or by the screen name applied to the server.
▪
Click on the check-box of the desired server to select it.
◦
Click on the OK button to close the Macro Settings window.
◦
Click on the Save button to save the settings applied to the Macro (Figure 9).
•
To delete a Macro:
◦
Click on the desired Macro to highlight it.
◦
Click on the Delete button to delete the selected Macro (Figure 9).
◦
Click on the Save button when finished (Figure 9).
