109
Chapter 6 Configure the Router in Range Extender Mode
• Wireless 2.4GHz/5GHz - This field displays the basic information or status of the
wireless function, and you can configure them on the Wireless 2.4GHz/5GHz > Basic
Settings page.
• Operation Mode - The current operation mode of the router.
• Wireless Radio - Indicates whether the wireless feature is enabled or not.
• Name (SSID) of Root AP - The SSID of the connected host network.
• Name (SSID) - The SSID of the network.
• Mode - The current wireless working mode in use.
• Channel Width - The current wireless channel width in use.
• Channel - The current wireless channel in use.
• MAC Address - The physical address of the router.
• System Up Time - The length of the time since the router was last powered on or
reset.
Click Refresh to get the latest status and settings of the router.
6. 2. Operation Mode
1. Visit http://tplinkwifi.net , and log in with the username and password you set for the
router.
2. Go to Operation Mode .
3. Select the operation mode as needed and click Save .
6. 3. Network
6. 3. 1. LAN
1. Visit http://tplinkwifi.net , and log in with the username and password you set for the
router.
2. Go to Network > LAN .
3. Configure the IP parameters of the LAN and click Save .
