192
Chapter 8 Configure the Router in Hotspot Router Mode
Done!
Now only the specific host(s) can visit the target(s) within the scheduled time period.
8. 11. Advanced Routing
Static Routing is a form of routing that is configured manually by a network administrator
or a user by adding entries into a routing table. The manually-configured routing
information guides the router in forwarding data packets to the specific destination.
8. 11. 1. Static Routing List
1. Visit http://tplinkwifi.net , and log in with the username and password you set for the
router.
2. Go to Advanced Routing > Static Routing .
• To add static routing entries:
1. Click Add New .
2. Enter the following information .
• Destination IP Address - The Destination IP Address is the address of the
network or host that you want to assign to a static route.
• Subnet Mask - The Subnet Mask determines which portion of an IP address is
the network portion, and which portion is the host portion.
• Gateway - This is the IP address of the default gateway device that allows the
contact between the router and the network or host.
• Interface - It is empty by default. Please select a connection from the drop-
down list if the Gateway is left empty or is not on the same network segment as
LAN/WAN interface.
3. Select Enabled or Disabled for this entry on the Status drop-down list.
4. Click Save.
You can also do the following operations to modify the current settings.
• Click
Delete Selected to delete selected entries.
