205
Chapter 8 Configure the Router in Hotspot Router Mode
• Traffic Statistics - Enable or Disable. The default value is disabled. To enable, click
the Enable button. If disabled, the function of DoS protection in Security settings will
disabled.
• Statistics Interval - The default value is 10. Select a value between 5 and 60 in the
drop-down list. The Packets Statistic Interval indicates the time section of the packets
statistic.
• Click Refresh to refresh immediately.
• Click Reset All to reset the values of all the entries to zero.
• Click Delete All to delete all entries in the table.
Statistics Table
IP/MAC Address The IP and MAC address are displayed with related statistics.
Total
Packets The total number of packets received and transmitted by the router.
Bytes The total number of bytes received and transmitted by the router.
Current
Packets
The total number of packets received and transmitted in the last Packets Statistic interval
seconds.
Bytes The total number of bytes received and transmitted in the last Packets Statistic interval seconds.
ICMP Tx
The number of the ICMP packets transmitted to WAN per second at the specified Packets
Statistics interval. It is shown like “current transmitting rate / Max transmitting rate”.
UDP Tx
The number of UDP packets transmitted to the WAN per second at the specified Packets
Statistics interval. It is shown like “current transmitting rate / Max transmitting rate”.
TCP
SYN Tx
The number of TCP SYN packets transmitted to the WAN per second at the specified Packets
Statistics interval. It is shown like “current transmitting rate / Max transmitting rate”.
Operation
Reset Reset the value of the entry to zero.
Delete Delete the existing entry in the table.
8. 16. Log Out
Click Logout at the bottom of the main menu, and you will log out of the web management
page and return to the login window.
