7
Chapter 2 Connect the Hardware
2. 2. 2. Access Point Mode
Create a wireless network from an Ethernet connection. This mode is suitable for dorm
rooms or homes where there’s already a wired router but you need a wireless network.
1. Switch the operating mode to
AP/Rng Ext/Client and connect the hardware according
to Step A to D.
2. Connect your device to the router wirelessly. The Wi-Fi network name and password
are on the router’s label.
Note : If the hotel’s internet has an authentication process, you will need to authenticate it on EACH device.
Internet
B C D A Wired Router
2. 2. 3. Range Extender Mode
Repeat signal from an existing wireless network. This mode is suitable to extend wireless
coverage, reaching devices that were previously too far from your primary router to
maintain a stable wireless connection.
1. Switch the operating mode to
AP/Rng Ext/Client and plug the router into an electrical
outlet near your host AP.
2. Connect your device to the router wirelessly or via an Ethernet cable. The Wi-Fi
network name and password are on the router’s label.
Internet
A B
Host AP
2. 2. 4. Client Mode
In this mode, this device can be connected to another device via an Ethernet cable and
act as an adapter to grant your wired devices access to a wireless network, especially
for a smart TV, media player, or game console.
