TP-Link TL-WR902AC AC750 Wireless Dual-Band Travel Router User Manual
Page 30
23
Chapter 4
Configure the Router in Wireless Router Mode
•
PPP Username/Password
- Enter the username and password provided by your ISP.
These fields are case-sensitive.
•
Confirm Password
- Enter the Password provided by your ISP again to ensure the
password you entered is correct.
•
Secondary Connection
- It’s available only for PPPoE connection. If your ISP provides
an extra connection type, select
Dynamic IP
or
Static IP
to activate the secondary
connection.
•
Connection Mode
•
Always On
- Connect automatically after the router is connected.
•
Connect on demand
- In this mode, the internet connection can be terminated
automatically after a specified inactivity period (Max Idle Time) and be re-
established when you attempt to access the internet again. If you want to keep
your internet connection active all the time, please enter 0 in the
Max Idle Time
field. Otherwise, enter the number of minutes you want to have elapsed before
your internet access disconnects.
•
Connect manually
- You can click
Connect/Disconnect
to connect/disconnect
immediately. This mode also supports the
Max Idle Time
function as
Connect
on demand
mode. The internet connection can be disconnected automatically
after a specified inactivity period (Max Idle Time) and not be able to re-establish
when you attempt to access the internet again.
Note:
• Only when you have configured the system time on the
System Tools
>
Time Settings
page, will the
time-based connecting function take effect.
• Sometimes the connection cannot be terminated although you have specified the
Max Idle Time
because
some applications are visiting the internet continually in the background.
If you want to do some advanced configurations, please click
Advanced
.
•
Service Name/Server Name
- The service name and server name should not be
configured unless you are sure it is necessary for your ISP. In most cases, leaving
these fields blank will work.
•
MTU(Bytes)
- The default MTU size is 1480 bytes. It is not recommended that you
change the default MTU size unless required by your ISP.
