TP-Link TL-WR902AC AC750 Wireless Dual-Band Travel Router - Manual (Page 175)

168
Chapter 8 Configure the Router in Hotspot Router Mode
• Guest Network Isolation - If enabled, one guest can not communicate with another.
• Guest Network Bandwidth Control - If enabled, the Guest Network Bandwidth Control
rules will take effect.
• Band Select - Select the wireless band 2.4GHz or 5GHz for the guest network.
• Guest Network - Enable or disable the guest network .
• Network Name - Enter a value of up to 32 characters. The same Name(SSID) must be
assigned to all wireless devices in your guest network.
• Max Guests number - Maximum guests (1-32).
• Security - You can configure the security of the guest network here.
• Access Time - You can also specify when or how long a guest device can access the
internet.
• Schedule - During this time the wireless stations could not access the guest
network.
• Timeout - If the countdown timer hits zero, the guest network will be closed.
8. 5. DHCP
By default, the DHCP (Dynamic Host Configuration Protocol) Server is enabled and the
router acts as a DHCP server; it dynamically assigns TCP/IP parameters to client devices
from the IP Address Pool. You can change the settings of DHCP Server if necessary,
and you can reserve LAN IP addresses for specified client devices.
