27
Chapter 4 Configure the Router in Wireless Router Mode
• Username/Password - Enter the username and password provided by your ISP. These
fields are case-sensitive.
• Confirm Password - Enter the Password provided by your ISP again to ensure the
password you entered is correct.
• Connect/Disconnect - Click this button to connect or disconnect immediately.
• Addressing Type - Select either as required by your ISP. If Static IP is selected, please
enter the IP address, subnet marsk, gateway and DNS also provided by your ISP.
• Internet IP Address/ Internet DNS - The internet IP address and DNS server address
assigned by L2TP server.
• MTU(Bytes) - The default MTU size is 1480 bytes. It is not recommended that you
change the default MTU size unless required by your ISP.
• IGMP Proxy - Select to enable the IGMP Proxy feature if the IPTV service provided by
the ISP is IGMP techonology-based.
• Connection Mode
• Always On - Connect automatically after the router is connected.
• Connect on demand - In this mode, the internet connection can be terminated
automatically after a specified inactivity period (Max Idle Time) and be re-
established when you attempt to access the internet again. If you want to keep
your internet connection active all the time, please enter 0 in the
Max Idle Time
field. Otherwise, enter the number of minutes you want to have elapsed before
your internet access disconnects.
• Connect manually - You can click Connect/Disconnect to connect/disconnect
immediately. This mode also supports the Max Idle Time function as Connect
on demand mode. The internet connection can be disconnected automatically
after a specified inactivity period (Max Idle Time) and not be able to re-establish
when you attempt to access the internet again.
Note: Sometimes the connection cannot be terminated although you have specified the Max Idle Time because some
applications are visiting the internet continually in the background.
4. 2. 2. 3G/4G Settings
To use the 3G/4G function, you should first insert a 3G/4G USB modem into the 3G/4G
USB port of the router. There is already much 3G/4G USB modem information embedded
in th router. The USB modem parameters will be set automatically if the SIM/UIM card is
supported by the router.
Note: 3G/4G modem is only supported in some regions.
1. Visit http://tplinkwifi.net , and log in with the username and password you set for the
router.
2. Go to Network > 3G/4G Settings .
