TP-Link TL-WR902AC AC750 Wireless Dual-Band Travel Router - Manual (Page 17)

10
Chapter 3 Set Up Internet Connection Via Quick Setup Wizard
3. 1. Log In to the Router
With a web-based utility, it is easy to configure and manage the router. The web-based
utility can be used on any Windows, Macintosh or UNIX OS with a web browser, such as
Microsoft Internet Explorer, Mozilla Firefox or Apple Safari.
Follow the steps below to log in to your router.
1. Set up the TCP/IP Protocol in
Obtain an IP address automatically mode on your
computer.
2. Visit http://tplinkwifi.net , and log in with the username and password you set for the
router. The default one is admin (all lowercase) for both username and password.
Note: If the login window does not appear, please refer to FAQ .
3. 2. Configure the Router
The Quick Setup Wizard will guide you through the process to set up your router.
3. 2. 1. Standard Wireless Router Mode
1. Select the WAN Connection Type . When using the router in a hotel room or a small
office, select Dynamic IP .
Note:
• If you use DSL line and you are only provided an account name and a password by your ISP, choose
PPPoE .
• If you use cable TV or fiber cable, choose Dynamic IP .
• If you are provided more information such as IP address, Subnet Mask and Default Gateway, choose
Static IP .
• Contact your ISP if you are not sure about the WAN connection information. You can also select Auto-
Detect to let the router detect your connection type automatically.
