Power SuPPly ComPonent rePlaCement
9-52
powermax
105 Service Manual
380 V CCC/400 V CE heat sink components
Input diode
bridge (Kit
128746)
Inverter IGBT
module (Kit
228702)
Pilot arc IGBT
(Kit 228944)
Output diode
bridge (2) (Kit
228902)
Thermal sensor
(Kit 228805)
Inverter IGBT
module gate drive
cables
Pilot arc IGBT gate
drive cable
Snubber resistor
15Ω 200W
(Kit 228898)
Snubber resistor
5Ω 200W
(Kit 228897)
Torque to 17.3 kg cm (15 in.-lbs).
M4 X 10 2SEM
Torque to 11.5 kg cm (10 in.-lbs).
M3 X 10 1SEM
1
2
Torque to 40 kg cm (35 in.-lbs).
M6 X 16-12.5 2SEM TRI CHRM
3
1
1
3
3
3
3
