116 Programming: Fundamentals, file management
3.4 W
o
rk
ing with the file manag
e
r
The TNC in a network
If the TNC is connected to a network, the directory window displays
additional drives (see figure). All the functions described above
(selecting a drive, copying files, etc.) also apply to network drives,
provided that you have been granted the corresponding rights.
Connecting and disconnecting a network drive
U To select the program management: Press the PGM
MGT key. If necessary, press the WINDOW soft key
to set up the screen as it is shown at the upper right.
U To select the network settings: Press the NETWORK
soft key (second soft key row).
U To manage the network drives: Press the
DEFINE NETWORK CONNECTN. soft key. The TNC
displays possible network drives to which you have
access in a window. With the soft keys described
below you can define the connection for each drive.
To connect the Ethernet card to your network, see
"Ethernet interface", page 427.
The TNC logs error messages during network operation
see "Ethernet interface", page 427.
Function Soft key
Establish the network connection. If the connection
is active, the TNC marks the Mount column. Connect
Delete the network connection. Unmount
Automatically establish network connection
whenever the TNC is switched on. The TNC marks
the Auto column if the connection is established
automatically Auto
Set up new network connection Add
Delete existing network connection Remove
Copy network connection Copy
Edit network connection Edit
Clear status window Clear
