HEIDENHAIN TNC 620 441
1
7.1 Mac
h
ine-specific user par
a
met
e
rs
DisplaySettings
Display step for the individual axes
List of all available axes
Display step for position display in mm or degrees
0.1
0.05
0.01
0.005
0.001
0.0005
0.0001
0.00005 (Display step software option)
0.00001 (Display step software option)
Display step for position display in inches
0.005
0.001
0.0005
0.0001
0.00005 (Display step software option)
0.00001 (Display step software option)
DisplaySettings
Definition of the unit of measure valid for the display
metric: Use metric system
inch: Use inch system
DisplaySettings
Format of the NC programs and cycle display
Program entry in HEIDENHAIN plain language or in DIN/ISO
HEIDENHAIN: Program entry in plain language in MDI mode
ISO: Program entry in MDI mode in DIN/ISO format
Depiction of the cycles
TNC_STD: Display the cycles with comments
TNC_PARAM: Display the cycles without comments
Parameter settings
