7.1 Mac
h
ine-specific user par
a
met
e
rs
ProbeSettings
Configuration of probing behavior
Manual operation: Including basic rotation
TRUE: Including active basic rotation during probing
FALSE: Always move on paraxial path during probing
Automatic mode: Multiple measurements in probing functions
1 to 3: Probe points per probing process
Automatic mode: Confidence interval of multiple measurements
0.002 to 0.999 [mm]: Range within which the measured value must be during multiple measurements
CfgTTRoundStylus
Coordinates of the stylus center
[0]: X coordinate of the stylus center with respect to the machine datum
[1]: Y coordinate of the stylus center with respect to the machine datum
[2]: Z coordinate of the stylus center with respect to the machine datum
Safety clearance above the stylus for pre-positioning
0.001 to 99 999.9999 [mm]: Setup clearance in tool-axis direction
Safety zone around the stylus for pre-positioning
0.001 to 99 999.9999 [mm]: Setup clearance in the plane perpendicular to the tool axis
CfgToolMeasurement
M function for spindle orientation
–1: Spindle orientation directly by the NC
0: Function inactive
1 to 999: Number of the M function for spindle orientation
Probing direction for tool radius measurement
X_Positive, Y_Positive, X_Negative, Y_Negative (depending on the tool axis)
Distance from lower edge of tool to upper edge of stylus
0.001 to 99.9999 [mm]: Offset of stylus to tool
Rapid traverse in probing cycle
10 to 300 000 [mm/min]: Rapid traverse in probing cycle
Probing feed rate for tool measurement
1 to 3 000 [mm/min]: Rapid traverse during tool measurement
Calculation of the probing feed rate
ConstantTolerance: Calculation of the probing feed rate with constant tolerance
VariableTolerance: Calculation of the probing feed rate with variable tolerance
ConstantFeed: Constant probing feed rate
Max. permissible surface cutting speed at the tooth edge
1 to129 [m/min]: Permissible surface cutting speed at the circumference of the milling tool
Maximum permissible speed during tool measurement
0 to 1 000 [1/min]: Maximum permissible speed
Maximum permissible measuring error for tool measurement
0.001 to 0.999 [mm]: First maximum permissible measurement error
Maximum permissible measuring error for tool measurement
0.001 to 0.999 [mm]: Second maximum permissible measurement error
