362 Manual operation and setup
13.5 Using 3-D t
ouc
h pr
obes
13.5 Using 3-D touch probes
Overview
The following touch probe cycles are available in the Manual Operation
mode:
HEIDENHAIN only gives warranty for the function of the
probing cycles if HEIDENHAIN touch probes are used.
If you use probing functions in a tilted working plane, you
must set 3-D ROT to Active for the Manual Operation and
Automatic operating modes.
Function Soft key Page
Calibrating the effective length Page 366
Calibrating the effective radius Page 367
Measuring a basic rotation using a line Page 370
Setting the datum in any axis Page 371
Setting a corner as datum Page 372
Setting a circle center as datum Page 373
Touch probe system data
management See User’s
Manual for
Cycles
For more information about the touch probe table, refer to
the User’s Manual for Cycle Programming.
