5.2 T
ool data
Entering tool data in the table
You can define and store up to 9999 tools and their tool data in a tool
table. Also see the Editing Functions later in this Chapter. In order to
be able to assign various compensation data to a tool (indexing tool
number), insert a line and extend the tool number by a dot and a
number from 1 to 9 (e.g. T 5.2).
You must use tool tables if
„ you wish to use indexed tools such as stepped drills with more than
one length compensation value
„ your machine tool has an automatic tool changer
„ you want to rough-mill the contour with Cycle G122, (see "User's
Manual for Cycle Programming, ROUGH-OUT")
„ you want to work with Cycles 251 to 254 (see "User's Manual for
Cycle Programming," Cycles 251 to 254)
Tool table: Standard tool data
If you create or manage further tool tables, the file name
has to start with a letter.
You can select either list view or form view for tables via
the "Screen layout" key.
Abbr. Inputs Dialog
T Number by which the tool is called in the program (e.g. 5, indexed:
5.2) -
NAME Name by which the tool is called in the program (no more than 16
characters, all capitals, no spaces) Tool name?
L Compensation value for tool length L Tool length?
R Compensation value for the tool radius R Tool radius R?
R2 Tool radius R2 for toroid cutters (only for 3-D radius compensation
or graphical representation of a machining operation with
spherical or toroid cutters) Tool radius R2?
DL Delta value for tool length L Tool length oversize?
DR Delta value for tool radius R Tool radius oversize?
DR2 Delta value for tool radius R2 Tool radius oversize R2?
LCUTS Tooth length of the tool for Cycle 22 Tooth length in the tool axis?
ANGLE Maximum plunge angle of the tool for reciprocating plunge-cut in
Cycles 22 and 208 Maximum plunge angle?
TL Set tool lock (TL: for Tool Locked) Tool locked?
Yes = ENT / No = NO ENT
RT Number of a replacement tool, if available (RT: for Replacement
Tool; see also TIME2) Replacement tool?
