444

Tables and overviews

1

7.1 Mac

h

ine-specific user par

a

met

e

rs

ChannelSettings

CH_NC

Active kinematics

Kinematics to be activated

List of machine kinematics

Geometry tolerances

Permissible deviation from the radius

0.0001 to 0.016 [mm]: Permissible deviation of the radius at the circle end-point compared with
the circle start-point

Configuration of the fixed cycles

Overlap factor for pocket milling

0.001 to 1.414: Overlap factor for Cycle 4 POCKET MILLING and Cycle 5 CIRCULAR POCKET
MILLING

Display the "Spindle?" error message if M3/M4 is not active

On: Issue error message
Off: No error message

Display the "Enter a negative depth" error message

On: Issue error message
Off: No error message

Behavior when moving to wall of slot in the cylinder surface

LineNormal. Approach on a straight line
CircleTangential: Approach on a circular path

M function for spindle orientation

–1: Spindle orientation directly by the NC
0: Function inactive
1 to 999: Number of the M function for spindle orientation

Parameter settings
