7 optional block skip, Application, Inserting the "/" character – HEIDENHAIN TNC 620 (73498x-01) ISO programming User Manual
Page 415: Erase the "/" character, 7 optional bloc k skip 15.7 optional block skip
HEIDENHAIN TNC 620
415
15.7 Optional bloc
k skip
15.7 Optional block skip
Application
In a test run or program run, the control can skip over blocks that begin
with a slash "/":
U
To run or test the program without the blocks
preceded by a slash, set the soft key to ON.
U
To run or test the program with the blocks preceded
by a slash, set the soft key to OFF.
Inserting the "/" character
U
In the Programming mode you select the block in which the character
is to be inserted
U
Select the INSERT soft key
Erase the "/" character
U
In the Programming mode you select the block in which the character
is to be deleted
U
Select the REMOVE soft key
This function does not work for TOOL DEF blocks.
After a power interruption the TNC returns to the most
recently selected setting.
