HEIDENHAIN TNC 620 221
8.7 A
d
ditional functions
D14: ERROR: Displaying error messages
With the function D14 you can call messages under program control.
The messages are predefined by the machine tool builder or by
HEIDENHAIN. Whenever the TNC comes to a block with D14 in the
Program Run or Test Run mode, it interrupts the program run and
displays a message. The program must then be restarted. The error
numbers are listed in the table below.
Example NC block
The TNC is to display the text stored under error number 254:
Error message predefined by HEIDENHAIN
Range of error numbers Standard dialog text
0 ... 999 Machine-dependent dialog
1000 ... 1199 Internal error messages (see table)
N180 D14 P01 254 *
Error number Text
1000 Spindle?
1001 Tool axis is missing
1002 Tool radius too small
1003 Tool radius too large
1004 Range exceeded
1005 Start position incorrect
1006 ROTATION not permitted
1007 SCALING FACTOR not permitted
1008 MIRROR IMAGE not permitted
1009 Datum shift not permitted
1010 Feed rate is missing
1011 Input value incorrect
1012 Incorrect sign
1013 Entered angle not permitted
1014 Touch point inaccessible
1015 Too many points
1016 Contradictory input
1017 CYCL incomplete
