5.2 T
ool data
Tool table: Tool data required for automatic tool measurement
For a description of the cycles for automatic tool
measurement, see the User's Manual for Cycle
Programming.
Abbr. Inputs Dialog
CUT Number of teeth (20 teeth maximum) Number of teeth?
LTOL Permissible deviation from tool length L for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L). Input
range: 0 to 0.9999 mm Wear tolerance: length?
RTOL Permissible deviation from tool radius R for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L). Input
range: 0 to 0.9999 mm Wear tolerance: radius?
R2TOL Permissible deviation from tool radius R2 for wear detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm Wear tolerance: Radius 2?
DIRECT. Cutting direction of the tool for measuring the tool during rotation Cutting direction (M3 = –)?
R_OFFS Tool radius measurement: Tool offset between stylus center and
tool center. Default setting: No value entered (offset = tool radius) Tool offset: radius?
L_OFFS Tool length measurement: tool offset in addition to
offsetToolAxis (114104) between upper surface of stylus and
lower surface of tool. Default: 0 Tool offset: length?
LBREAK Permissible deviation from tool length L for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm Breakage tolerance: length?
RBREAK Permissible deviation from tool radius R for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm Breakage tolerance: radius?
