8
TNC model, sof
tw
a
re
and f
eat
ur
es Advanced programming features (option number 19)
FK free contour programming
„ Programming in HEIDENHAIN conversational format with
graphic support for workpiece drawings not dimensioned for NC
Fixed cycles
„ Peck drilling, reaming, boring, counterboring, centering (Cycles
201 to 205, 208, 240, 241)
„ Milling of internal and external threads (Cycles 262 to 265, 267)
„ Finishing of rectangular and circular pockets and studs
(Cycles 212 to 215, 251 to 257)
„ Clearing level and oblique surfaces (Cycles 230 to 232)
„ Straight slots and circular slots (Cycles 210, 211, 253, 254)
„ Linear and circular point patterns (Cycles 220, 221)
„ Contour train, contour pocket—also with contour-parallel
machining (Cycles 20 to 25)
„ OEM cycles (special cycles developed by the machine tool
builder) can be integrated
Advanced graphic features (option number 20)
Program verification graphics, program-run graphics
„ Plan view
„ Projection in three planes
„ 3-D view
Software option 3 (option number 21)
Tool compensation
„ M120: Radius-compensated contour look-ahead for up to 99
blocks
3-D machining
„ M118: Superimpose handwheel positioning during program run
Pallet management (option number 22)
Pallet management
HEIDENHAIN DNC (option number 18)
Communication with external PC applications over COM
component
