Programming: Tools
5.2 T
ool data
There are two ways to run a tool usage test for a pallet file:
The highlight is on a pallet entry in the pallet file:
The TNC runs the tool usage test for the entire pallet.
The highlight is on a program entry in the pallet file:
The TNC runs the tool usage test for the selected program.
RAD
Tool radius R
+ Oversize of tool radius DR
from the tool table. (in mm)
BLOCK
Block number in which the TOOL CALL block
was programmed
PATH
TOKEN
= TOOL: Path name of the active main
program or subprogram
TOKEN
= STOTAL: Path name of the
subprogram
T
Tool number with tool index
OVRMAX
Maximum feed rate override that occurred
during machining. During test run, the TNC
enters the value 100 (%)
OVRMIN
Minimum feed rate override that occurred
during machining. During test run, the TNC
enters the value –1
NAMEPROG
0
: The tool number is programmed
1
: The tool name is programmed
