Reset the plane function – HEIDENHAIN TNC 620 (73498x-01) ISO programming User Manual
Page 310
310
Programming: Multiple axis machining
1
1
.2 The PLANE function: Tilting the
w
or
king plane (sof
tw
ar
e option 1)
Reset the PLANE function
U
Show the soft-key row with special functions
U
Select special TNC functions: Press the SPECIAL TNC
FUNCTIONS soft key
U
Select the PLANE function: Press the TILT
MACHINING PLANE soft key: The TNC displays the
available definition possibilities in the soft-key row
U
Select the Reset function. This internally resets the
PLANE
function, but does not change the current axis
positions
U
Specify whether the TNC should automatically move
the rotary axes to the default setting (MOVE or TURN) or
not (STAY) (see "Automatic positioning:
MOVE/TURN/STAY (entry is mandatory)" on page
324).
U
To terminate entry, press the END key
Example: NC block
25 PLANE RESET MOVE SET-UP50 F1000
The PLANE RESET function resets the current PLANE
function—or an active CycleG80—completely (angles = 0
and function is inactive). It does not need to be defined
more than once.
