HEIDENHAIN TNC 620 481
Comparison: Differences in Manual Operation,
functionality
Function TNC 620 iTNC 530
Manual probing cycles in the tilted
working plane (3D ROT: Active) Manual probing cycles in the tilted
working plane can only be used if 3D-
ROT for Manual and Automatic
operating modes is set to "Active". Manual probing cycles in the tilted
working plane can only be used if 3D-
ROT for Manual operating mode is set
to "Active".
Jog increment function The jog increment can be defined
separately for linear and rotary axes The jog increment applies for both linear
and rotary axes
Preset table Basic transformation (translation and
rotation) of machine table system to
workpiece system via the columns X, Y
and Z, as well as spatial angles SPA, SPB
and SPC.
In addition, the columns X_OFFS to
W_OFFS
can be used to define the axis
offset of each individual axis. The
function of the axis offsets can be
configured.
Basic transformation (translation) of
machine table system to workpiece
system via the columns X, Y and Z, as
well as a ROT basic rotation in the
working plane (rotation).
In addition, the columns A to W can be
used to define datums in the rotary and
parallel axes.
Behavior during presetting Presetting in a rotary axis has the same
effect as an axis offset. The offset is also
effective for kinematics calculations and
for tilting the working plane.
The machine parameter
CfgAxisPropKin->presetToAlignAxis
is
used to define whether the axis offset is
to be taken into account internally after
zero setting.
Independently of this, an axis offset has
always the following effects:
„ An axis offset always influences the
nominal position display of the
affected axis (the axis offset is
subtracted from the current axis
value).
„ If a rotary axis coordinate is
programmed in an L block, then the
axis offset is added to the
programmed coordinate.
Rotary axis offsets defined by machine
parameters do not influence the axis
positions that were defined in the Tilt
working plane function.
MP7500 bit 3 defines whether the
current rotary axis position referenced to
the machine datum is taken into
account, or whether a position of 0° is
assumed for the first rotary axis (usually
the C axis).
