HEIDENHAIN TNC 620 (73498x-01) ISO programming - Manual (Page 445)

HEIDENHAIN TNC 620 445
1
7.1 Mac
h
ine-specific user par
a
met
e
rs
Geometry filter for culling linear elements
Type of stretch filter
- Off: No filter active
- ShortCut: Omit individual points on a polygon
- Average: The geometry filter smoothes corners
Maximum distance of the filtered to the unfiltered contour
0 to 10 [mm]: The filtered points lie within this tolerance to the resulting new path
Maximum length of the distance resulting from filtering
0 to 1000 [mm]: Length over which geometry filtering is active
Settings for the NC editor
Generate backup files
TRUE: Generate backup file after editing NC programs
FALSE: Do not generate backup file after editing NC programs
Behavior of the cursor after deletion of lines
TRUE: Cursor is placed on the preceding line after deletion (iTNC behavior)
FALSE: Cursor is placed on the following line after deletion
Behavior of the cursor on the first or last line
TRUE: Cursor jumps from end to beginning of program
FALSE: Cursor does not jump from end to beginning of program
Line break with multiline blocks
ALL: Always display all lines
ACT: Only display the lines of the active block completely
NO: Only display all lines when block is edited
Activate help
TRUE: Always display help graphics during input
FALSE: Only display help graphics if HELP was activated by pressing the key
Behavior of the soft-key row after a cycle entry
TRUE: The cycle soft-key row remains active after a cycle definition
FALSE: The cycle soft-key row is hidden after a cycle definition
Safety check when deleting blocks
TRUE: Display confirmation question when deleting an NC block
FALSE: Do not display confirmation question when deleting an NC block
Program length for which the geometry is to be checked
100 to 9999: Program length for which the geometry is to be checked
Paths for the end user
List of drives and/or directories
Drives or directories entered here are shown in the TNC’s file manager
Universal time (Greenwich Mean Time)
Time difference to universal time [h]
–12 to 13: Time difference in hours relative to Greenwich Mean Time
Parameter settings
