HEIDENHAIN TNC 620
231
8.7 A
d
ditional functions
5
B axis
6
C axis
7
U axis
8
V axis
9
W axis
TS triggering touch probe, 350
50
1
Touch probe type
2
Line in the touch-probe table
51
-
Effective length
52
1
Effective ball radius
2
Rounding radius
53
1
Center offset (reference axis)
2
Center offset (minor axis)
54
-
Spindle-orientation angle in degrees (center offset)
55
1
Rapid traverse
2
Measuring feed rate
56
1
Maximum measuring range
2
Set-up clearance
57
1
Spindle orientation possible: 0=no, 1=yes
2
Angle of spindle orientation
TT tool touch probe
70
1
Touch probe type
2
Line in the touch-probe table
71
1
Center point in reference axis (REF system)
2
Center point in minor axis (REF system)
3
Center point in tool axis (REF system)
72
-
Probe contact radius
75
1
Rapid traverse
2
Measuring feed rate for stationary spindle
3
Measuring feed rate for rotating spindle
76
1
Maximum measuring range
Group name, ID no.
Number
Index
Meaning
