228 Programming: Q parameters
8.7 A
d
ditional functions
Pocket table data, 51 1 Pocket number Tool number
2 Pocket number Special tool: 0=no, 1=yes
3 Pocket number Fixed pocket: 0=no, 1=yes
4 Pocket number Locked pocket: 0=no, 1=yes
5 Pocket number PLC status
Pocket number of a tool in the
tool-pocket table, 52 1 Tool no. Pocket number
2 Tool no. Tool magazine number
Values programmed immediately
after TOOL CALL, 60 1 - Tool number T
2 - Active tool axis
0 = X 6 = U
1 = Y 7 = V
2 = Z 8 = W
3 - Spindle speed S
4 - Tool length oversize DL
5 - Tool radius oversize DR
6 - Automatic TOOL CALL
0 = Yes, 1 = No
7 - Tool radius oversize DR2
8 - Tool index
9 - Active feed rate
Values programmed immediately
after TOOL DEF, 61 1 - Tool number T
2 - Length
3 - Radius
4 - Index
5 - Tool data programmed in TOOL DEF
1 = Yes, 0 = No
Group name, ID no. Number Index Meaning
