HEIDENHAIN TNC 620
49
1
.6 W
o
rk
piece set
u
p
1.6 Workpiece setup
Select the correct operating mode
Workpieces are set up in the Manual Operation or Electronic
Handwheel
mode
U
Press the Manual Operation operating mode key: the
TNC switches to that mode.
Further information on this topic
Manual Operation mode: See "Moving the machine axes" on page
349
Clamping the workpiece
Mount the workpiece with a fixture on the machine table. If you have
a 3-D touch probe on your machine, then you do not need to clamp the
workpiece parallel to the axes.
If you do not have a 3-D touch probe available, you have to align the
workpiece so that it is fixed with its edges parallel to the machine
axes.
