4.2 Adding comments
Application
You can add comments to a part program to explain program steps or
make general notes.
Entering a comment in a separate block
U Select the block after which the comment is to be inserted.
U Press the SPEC FCT key to select the special functions
U Select the program functions: Press the PROGRAM FUNCTIONS
soft key
U Shift the soft-key row to the left
U Press the INSERT COMMENT soft key
U Enter your comment using the screen keyboard (see "Screen
keyboard" on page 120) and conclude the block by pressing the END
key
Enter the file name using the screen keyboard (see
"Screen keyboard" on page 120).
If the TNC cannot show the entire comment on the
screen, the >> sign is displayed.
The last character in a comment block must not have any
tilde (~).
If your TNC 620 has an alphabetic keyboard or if you have
connected a PC keyboard to the USB interface, you can
directly enter a comment block by pressing the ; key.
