HEIDENHAIN TNC 620 457
Miscellaneous functions
M Effect Effective at block... Start End Page
M0 Program run STOP/Spindle STOP/Coolant OFF „ Page 279
M1 Optional program STOP/Spindle STOP/Coolant OFF „ Page 416
M2 Program run STOP/Spindle STOP/Coolant OFF/Clear status display
(depending on machine parameter)/Go to block 1 „ Page 279
M3
M4
M5 Spindle ON clockwise
Spindle ON counterclockwise
Spindle STOP „
„
„
Page 279
M6 Tool change/Stop program run (depending on machine parameter)/Spindle STOP „ Page 279
M8
M9 Coolant ON
Coolant OFF „
„
Page 279
M13
M14 Spindle ON clockwise/Coolant ON
Spindle ON counterclockwise/Coolant ON „
„ Page 279
M30 Same function as M2 „ Page 279
M89 Vacant miscellaneous function or
Cycle call, modally effective (depending on machine parameter) „
„
Cycles
Manual
M91 Within the positioning block: Coordinates are referenced to machine datum „ Page 280
M92 Within the positioning block: Coordinates are referenced to position defined by machine
tool builder, such as tool change position „ Page 280
M94 Reduce the rotary axis display to a value below 360° „ Page 332
M97 Machine small contour steps „ Page 283
M98 Machine open contours completely „ Page 285
M99 Blockwise cycle call „ Cycles
Manual
M101
M102 Automatic tool change with replacement tool if maximum tool life has expired
Reset M101 „
„ Page 157
M109
M110
M111
Constant contouring speed at tool cutting edge
(increase and decrease feed rate)
Constant contouring speed at tool cutting edge
(feed rate decrease only)
Reset M109/M110 „
„
„
Page 287
M116
M117 Feed rate for rotary axes in mm/min
Reset M116 „
„
Page 330
M118 Superimpose handwheel positioning during program run „ Page 290
M120 Pre-calculate radius-compensated contour (LOOK AHEAD) „ Page 288
