HEIDENHAIN TNC 620 (73498x-01) ISO programming - Manual (Page 431)

HEIDENHAIN TNC 620 431
16.5 Ether
n
et int
e
rf
ace
U Apply the changes with the OK button, or discard them with the
Cancel
button
U The Internet tab currently has no function.
Domain Name
Server (DNS) „ Automatically procure DNS option:
The TNC is to automatically procure the IP
address of the domain name server
„ Manually configure the DNS option:
Manually enter the IP addresses of the
servers and the domain name
Default
gateway „ Automatically procure default gateway
option:
The TNC is to automatically procure the
default gateway
„ Manually configure the default gateway
option:
Manually enter the IP addresses of the default
gateway
Setting Meaning
Setting Meaning
Proxy „ Direct connection to Internet/NAT :
The control forwards Internet inquiries to the
default gateway and from there they must be
forwarded through network address
translation (e.g. if a direct connection to a
modem is available)
„ Use proxy :
Define the Address and Port of the Internet
router in your network, ask your network
administrator for the correct address and port
Telemaintenance The machine manufacturer configures the server
for telemaintenance here. Changes must always
be made in agreement with your machine tool
builder.
