Comparison: Touch probe cycles for automatic
workpiece inspection
Cycle TNC 620 iTNC 530
0, Reference plane X, option 17 X
1, Polar datum X, option 17 X
2, Calibrating TS – X
3, Measuring X, option 17 X
4, Measuring in 3-D – X
9, Calibrating TS length – X
30, Calibrating TT X, option 17 X
31, Measuring tool length X, option 17 X
32, Measuring tool radius X, option 17 X
33, Measuring tool length and radius X, option 17 X
400, Basic rotation X, option 17 X
401, Basic rotation from two holes X, option 17 X
402, Basic rotation from two studs X, option 17 X
403, Compensating a basic rotation via a rotary axis X, option 17 X
404, Setting a basic rotation X, option 17 X
405, Compensating workpiece misalignment by rotating the C axis X, option 17 X
408, Slot center datum X, option 17 X
409, Ridge center datum X, option 17 X
410, Datum from inside of rectangle X, option 17 X
411, Datum from outside of rectangle X, option 17 X
412, Datum from inside of circle X, option 17 X
413, Datum from outside of circle X, option 17 X
414, Datum at outside corner X, option 17 X
415, Datum at inside corner X, option 17 X
416, Datum at circle center X, option 17 X
417, Datum in touch probe axis X, option 17 X
418, Datum at center of 4 holes X, option 17 X
