6.1 Basic Operation
6-13
6
Changing Function Selection Parameter Settings
Using the Hand-held Digital Operator
1. Press DSPL/SET Key to select the parameter setting mode.
2. Select the parameter number to be set.
Press the Left or Right Cursor Key to select the digit. The selected digit will flash. Press
the Up or Down Key to change the value. (Pn000 is selected in this example.)
3. Press the DATA/ENTER Key to display the current data of the parameter selected in the
above step 2.
4. Press the Left or Right Cursor Key to select the digit.
5. Press the Up or Down Cursor Key to select the value defined as a function setting for the
selected digit.
Repeat the above steps 4. and 5. for changing the data as required.
6. Press the DATA/ENTER Key to save the data. The display will flash.
7. Press the DATA/ENTER Key once more to return to the parameter number display.
This has changed the 1st digit of parameter Pn000 to “1.”
Digit to be set
Digit to be set
Digit to be set
