Appendix A List of Parameters

A-6

A.2 Switches

The following list shows the switches and their factory settings.

Table A.2 List of Switches

Parameter

Digit

Place

Name

Setting

Contents

Factory

Setting

Pn000
Function
Selection
Basic
Switches

0

Rotation Direction
Selection

0

Sets CCW as forward direction.

0

1

Sets CW as forward direction (reverse rotation mode).

1

Control Method
Selection

0

Speed control (analog reference)

0

1

Position control (pulse train reference)

2

Torque control (analog reference)

3

Internal set speed control (contact reference)

4

Internal set speed control (contact reference)/Speed con-
trol (analog reference)

5

Internal set speed control (contact reference)/Position con-
trol (pulse train reference)

6

Internal set speed control (contact reference)/Torque con-
trol (analog reference)

7

Position control (pulse train reference)/Speed control (ana-
log reference)

8

Position control (pulse train reference)/Torque control
(analog reference)

9

Torque control (analog reference)/Speed control (analog
reference)

A

Speed control (analog reference)/Zero clamp

B

Position control (pulse train reference)/Position control
(Inhibit)

2

Axis Address

0 to F

Sets SERVOPACK axis address.

0

3

Reserved

-

0
