INSTALLATION
20
Front View Rear View
1. Disk Activity LED
2. Disk Fault/Link LED
3. LCD Panel with Keypad
4. Thunderbolt & USB 3.2 Port1
5. Thunderbolt & USB 3.2 Port2
6. Display Port
7. LAN Port
8. SAS Expansion Port
9. Reset Button
10. System Fan1
11. System Fan2
12. Power Supply Fan
13. Power Connector
The following diagram is the ARC-8050T3U 12-bay RAID storage
front view and rear view.
