Super Systems Inc Page 116 of 172 Super Data Operations Manual
Link Screen Buttons
A Link Screen Button is a button that will cause a new screen to be loaded and started. Link screen buttons can have
their background color changed by a separate data value. If the text and background colors happen to be the same,
the button is disabled (grayed out) and will not work until the background color is changed. A Link Screen Button can
send a Data Value in the current screen (the Pass Value) to the new screen, where it will be known as the Inherited
Value.
Properties
Name - The Name property makes the object easier for the RealEdit programmer to identify. Often it is a good idea
to use the same name for related objects, such as a Data Value that represents a Constant.
Screen - The File Reference of the Screen file
Top - The top position, in twips, of the object.
Left - The Left position, in twips, of the object.
Height - The Height value, in twips, of the object.
Width - The Width value, in twips, of the object.
Font - The type face selected for this particular text.
Value To Pass - The fundamental data unit for RealTime. A Data Value may be changed by a Data Process and can
be derived from any number of Data Sources.
Text Color - Color of the object’s display text
Clear Parent Screen - True/False value indicating whether the specified item will be applied to this object
Back Color Idx - The Value that determines which background color from the list will be displayed
Tip - ToolTip text to display. The ToolTip text floats over the object when the mouse pointer is hovered within the
object’s bounds.
Back Color List - This is a list of any object type. Selecting (list) invokes the List Builder Dialog.
Tab Index - Controls the order in which objects are selected by using the tab key. This value is this objects position
in the sequence.
Use As Color Display - True/False value indicating whether the specified item will be applied to this object
