NOLOG Optional. Applies to ALL instruments. Do not log data from this channel.
Include this when communications are required for real-time data but are not
required for historical data logging. If this is not included, the channel will be
data logged at one minute intervals.
ABC Optional. Applies to ALL instruments. Alarm Block Configuration . Caution:
any specified channel can use either ALM or ABC but not both. Allows a
custom Alarm Block Bitmap (one word) to be setup for any instrument but
generally used only for non-programmable instruments that are not capable of
maintaining alarm bitmaps. See the section on Custom Alarm Block
Configuration.
TAG Required. Applies to ALL instruments. Instrument name. Limited to 12
Characters with no spaces.
MMI V4 Instruments
[C]CH#LLL(PPP ) = "ID,[PROG],[ACW ],[BLK],[NOLOG],[DPOL],[ALM],[ABC] " = "tag "
Examples:
CH#1(1) = "DUALPRO-V4.0, PROG(1), ACW:E3, ALM(36,0,0,0,0)" = "CH1"
CH#20(1-29) = "MMIGEN-V4.0, BLK:012,ALM(1,800,2,14,12)" = "CH1_T29"
CH#21(1-27) = "MMIGEN-V4.0, BLK:345, NOLOG" = "1_XXX"
CH#2(2) = "DUALPRO-V4.0, PROG(3), ACW:E3, ALM(36,0,0,0,0)" = "CH2"
Note: Items enclosed in brackets [ ] are optional but may be required for certain instrument types.
Item Definition
C Optional. Applies to ALL instruments. Specifies the Connection Identifier (1-8
for serial connections and 9 for Ethernet). The protocol for the connection
must match the protocol for the instrument. If not included, defaults to
Connection 1.
LLL Required. Applies to ALL instruments. The logical channel number assigned (1-
128).
PPP Required. Applies to ALL instruments. (see MMI Instrument Physical
Addresses )
ID Required. Applies to ALL instruments. The instrument ID: DUALPRO-V4.0,
CARBPRO-V4.0, UNIPRO-V4.0, MMIGEN-V4.0, DPSTD-V4.0
PROG Optional. Applies to DUALPRO-V4.0, DPSTD-V4.0. Type of programs run in
the Foreground of a Dualpro instrument. Set this as PROG(1) if using LOGIC
programs in the Foreground. as PROG(2) for RECIPE programs in older
Dualpros (ver 4.87 and earlier) and as PROG(3) for RECIPE programs in all
newer Dualpros.
ACW Optional. Applies to DUALPRO-V4.0. Alarm Control Word. Used with
Dualpros running special applications. Set this to the Hex parameter of the
ACW defined in the Dualpro's Background application program (e.g., ACW:EF).
BLK Optional. Applies to MMIGEN-V4.0. Poll blocks. Used with MMIGEN-V4.0 to
specify which blocks to poll (3 maximum) (e.g., BLK:038 will poll blocks 0, 3,
and 8). Each block contains 24 words of data.
Block 0 = words 0-23 (x00-
x17) Block 1 = words 24-47 (x18-x2F) Note: the 10Pro-E and 10Pro-L have
only 1 block: Block 0. All other instruments will normally have 10 blocks:
Blocks 0-9
DPOL Optional. Applies to MMIGEN-V4.0. Poll this channel only on demand.
Normally, all channels are continuously polled. When demand polling is set,
the channel will be polled only when the Demand Poll Word (DPW) changes. If
used, the DPW will be defined in the Dualpro's Background program and the
parameter specified here must match that definition. (e.g., DPOL:EE).
ALM Optional. Applies to DUALPRO-V4.0, MMIGEN-V4.0. The ALARM configuration
