V T 1 0 0 I n t e r f a c e 4-5
The System screen displays the user-selectable prompts listed below.
Maintenance Reset
When you perform a Maintenance Reset, all configurations will be lost and
the unit will be set back to the factory default Ethernet or Serial HDLC
configuration. Either default configuration will set up an ATM service on the
Network port, using one configured virtual channel (VPI=0, VCI=32).
Management data received on this ATM channel (either Web or SNMP) will
be processed at the unit if it is encapsulated using RFC1483 and directed to
the unit’s IP address. (A Maintenance Reset will not change the unit’s IP
address.) The default serial HDLC configuration will also accept PPPoA
encapsulated data and deliver it to the Serial port. If you select “Maintenance
Reset,” a confirmation screen (Figure 4.4) will give you the option to proceed
with the reset or not.
Figure 4.4 Confirmation Screen
Save and Restart
Selecting “Save and Restart” will display a confirmation menu similar to the
one shown in Figure 4.4. Select “yes” to save the current configuration
settings and proceed with the restart.
NOTICE:
Performing a “Maintenance Reset” or a “Save and Restart” will
terminate communications with the unit. Refresh (by pressing “Ctrl+U”)
after approximately 10 seconds to restore communications.
Prompt Function
Maintenance Reset - Ethernet
Maintenance Reset - Serial HDLC
Displays a Confirmation screen that lets you reset
the unit to its default Ethernet or Serial HDLC
configuration.
Save and Restart Saves the current configuration and restarts.
