11-2
Reference
Specifications
● Facsimile
Type....................................................................Desktop transceiver
Compatibility .....................................................Group 3
Line Requirement..............................................Subscription telephone line
Transmission Speed.........................................Within 7 seconds (our proprietary ITU-T #1 chart, MMR, Memory transmission,
Normal resolution, Normal contrast)
Modem Speed....................................................14400/12000/9600/7200/4800/2400bps with automatic fallback
Data Compression ............................................MH/MR/MMR
Scanning System ..............................................Horizontal scanning by contact image sensor
Maximum Document Width..............................216 mm
Automatic Document Feeder Capacity....................Max. 50 pages
Auxiliary Scanning Line Density .....................Horizontal/Vertical
Normal (8 dots/mm x 3.85 lines/mm)
Fine (8 dots/mm x 7.7 lines/mm)
Super Fine (8 dots/mm x 15.4 lines/mm)
Greyscale...........................................................64 levels
One-Touch Dial .................................................45 keys
Abbreviated Dial................................................100 numbers
Broadcast Transmission ..................................Max. 145 locations
Polling Reception..............................................Max. 145 locations
Error Correction ................................................ECM
Recording System ............................................Semiconductor laser and electrophotography
Recording Resolution ......................................600 dpi
Recording Paper ...............................................75 g/m
2 - 80 g/m 2 (A4R and Folio)
Paper Capacity ..................................................500 sheets (80 g/m 2 )
Memory Capacity ..............................................1.25MB
Management Reports .......................................Confirmation report, Activity Report
Power Supply ....................................................AC 230V, 50Hz
Dimensions (W x D x H)....................................425 mm x 505 mm x 436 mm
Weight ................................................................Approx. 21 kg (Without imaging unit installed)
Noise emission..................................................
70 dB (A)
Options ..............................................................Optional Cassette, Memory Board (2MB, 4MB, 8MB), RS-232C Board, Printer Board,
Dual Line Kit
● Dual Line Kit (Option)
Compatibility .....................................................Super Group 3
Line Requirement..............................................Subscription telephone line
Transmission Speed.........................................Within 3 seconds (our proprietary ITU-T #1 chart, JBIG, Memory transmission,
Normal resolution, Normal contrast)
Modem Speed....................................................33600/31200/28800/26400/24000/21600/19200/16800/14400/12000/9600/7200/4800/
2400bps with automatic fallback
Data Compression ............................................MH/MR/MMR/JBIG
Memory Capacity ..............................................1.25MB
Options ..............................................................Memory Board (2MB, 4MB,8MB)
(Specifications are subject to change without notice.)
Available Characters Table
Depending on the language in use in the message display,
it may be possible to use letters other than those in the
English alphabet, and which are specific to a particular
language.
These letters, when available, will be registered using one
touch key No. 10.
Refer to the table at right for the special letters and other
characters available for registering destination names, etc.
Available characters Display language
Д Е Ц Ш Ж ! = Danish
; ? [ ] % ! = Dutch
; ? [ ] % ! = English
Д Е Ц Ш Ж ! = Finnish
Π? [ ] % ! = French
Д Ь Ц Я % ! = German
È ? [ ] % ! = Italian
Б Г У Х Й К Н з Portuguese
a o ¿ ? ¡ ! Ñ = Spanish
Д Е Ц Ш Ж ! = Swedish
