● F-Code based Confidential transmission
(Continued from step 7, page 7-21)
8. Press an unregistered one-touch key.
9. Press the ENTER FUNCTION key.
7-22
6HFWLRQ
Fax operation (Other functions)
10. Enter the destination fax number.
* If you entered the fax number with the keypad, proceed to
step 11.
* If you entered the fax number with an abbreviated number or
one-touch key that is already registered with the appropriate
SUB (subaddress) and SID (subaddress ID), proceed to step 15.
11. Press the ENTER FUNCTION key.
12. Use the keypad to enter the appropriate SUB (subaddress).
(Max. 20 digits)
13. Press the ENTER FUNCTION key.
14. Use the keypad to enter the appropriate SID (subaddress ID).
(Max. 20 digits)
* If you do NOT need to enter a subaddress ID, proceed to
step 15.
15. Press the ENTER FUNCTION key.
To transmit documents to multiple destinations, repeat steps 10
through 15 until all desired fax numbers have been entered.
* If “EXCEEDS MAX. DEST” appears in the message display, the
number of fax numbers entered exceeds the acceptable limit.
16. Press the ENTER FUNCTION key once again.
17. Enter the desired name for the program key.
(Max. 16 characters)
* Refer to “
● Entering Characters”, page 2-21, for more detailed
information on entering characters.
18. Press the ENTER FUNCTION key.
19. If you want to designate a time for the transmission to begin, use
the keypad to enter the start time.
To have the transmission begin immediately after the program
key is pressed, proceed to step 20.
* The time should be set on a 24-hour time basis (00:00 - 23:59).
20. Press the ENTER FUNCTION key.
21. Registration for that program key is complete. Use the cursor
keys ( 씱 ) ( 씰 ) to select whether or not you want to continue
registering program keys.
22. Press the ENTER FUNCTION key.
* If you chose to continue registering program keys, return to
step 6, page 7-21. If you chose NOT to continue, the message
display will revert to the initial mode.
3 1(: ',$/

68%
6,'
1$0( $%&
7,0(
● Polling reception (Continued from step 7, page 7-21)
8. Press an unregistered one-touch key.
9. Press the ENTER FUNCTION key.
10. Enter the fax number of the transmitting party.
To receive documents from multiple fax machines, repeat steps
1 and 2 below until all desired fax numbers have been entered.
* The fax numbers can be entered with the keypad, abbreviated
numbers or one-touch keys.
* If “EXCEEDS MAX. DEST” appears in the message display, the
number of fax numbers entered exceeds the acceptable limit.
1 Enter a fax number.
2 Check the display and press the ENTER FUNCTION key.
11. Press the ENTER FUNCTION key.
12. Enter the desired name for the program key.
(Max. 16 characters)
* Refer to “
● Entering Characters”, page 2-21, for more detailed
information on entering characters.
13. Press the ENTER FUNCTION key.
14. If you want to designate a time for the reception to begin, use the
keypad to enter the start time.
To have the reception begin immediately after the program key is
pressed, proceed to step 15.
* The time should be set on a 24-hour time basis (00:00 - 23:59).
15. Press the ENTER FUNCTION key.
16. Registration for that program key is complete. Use the cursor
keys ( 씱 ) ( 씰 ) to select whether or not you want to continue
registering program keys.
17. Press the ENTER FUNCTION key.
* If you chose to continue registering program keys, return to
step 6, page 7-21. If you chose NOT to continue, the message
display will revert to the initial mode.
3 1(: ',$/

1$0( $%&
7,0(
