SS2R24G4i/SS2R48G4i
131
access-list <num> {deny | permit} {eigrp | gre
| igrp | ipinip | ip | <int>} {{<sIpAddr>
<sMask>} | any-source | {host-source
<sIpAddr>}} {{<dIpAddr>
<dMask>} |
any-destination | {host-destination <dIpAddr>}}
[precedence
<prec>] [tos
<tos>][time-range<time-range-name>]
Creates a numbered IP
extended IP access rule for
other specific IP protocol or all
IP protocols; if the numbered
extended access-list of
specified number does not
exist, then an access-list will
be created using this number.
no access-list <num>
Deletes a numbered extensive
IP access-list
(3)
Configuring a standard IP access-list basing on nomenclature
a. Create a name-based standard IP access-list
Command Explanation
Global Mode
ip access-list standard <name>
no ip access-list standard
<name>
Creates a standard IP access-list based on
nomenclature; the “no ip access-list
standard <name>
“ command delete the
name-based standard IP access-list
b. Specify multiple “permit” or “deny” rules
Command Explanation
Standard IP ACL Mode
[no] {deny | permit} {{<sIpAddr>
<sMask >} | any-source |
{host-source <sIpAddr>}}
Creates a standard name-based IP access
rule; the “no” form command deletes the
name-based standard IP access rule
c. Exit name-based standard IP ACL configuration mode
Command Explanation
Standard IP ACL Mode
Exit
Exits name-based standard
IP ACL configuration mode
(4)
Configuring an name-based extended IP access-list
a. Create an extended IP access-list basing on nomenclature
Command Explanation
Global Mode
ip access-list extended <name>
no ip access-list extended
<name>
Creates an extended IP access-list basing on
nomenclature; the “no ip access-list
extended <name>
“ command deletes the
name-based extended IP access-list
b. Specify multiple “permit” or “deny” rules
Command Explanation
Extended IP ACL Mode
