SS2R24G4i/SS2R48G4i
74
7.2.3.1 Introduction to Port Mirroring
Port mirroring refers to the duplication of data frames sent/received on a port to another port. The
duplicated port is referred to as mirror source port and the duplicating port is referred to as mirror
destination port. A protocol analyzer (such as Sniffer) or RMON monitoring instrument is often attached
to the mirror destination port to monitor and manage the network and diagnostic.
SS2R24/48G4i switch switch support one mirror destination port only. The number of mirror source
ports are not limited, one or more may be used. Multiple source ports can be within the same VLAN or
across several VLANs. The destination port and source port(s) can be located in different VLANs.
7.2.3.2 Port Mirroring Configuration Task List
1. Specify mirror source port
2. Specify
mirror dentistination port
1. Specify mirror source port
2. Specify mirror dentistination port
Command Explanation
Port mode
monitor session <session> destination interface
<interface-number>
no monitor session <session> destination
interface <interface-number>
Specify mirror dentistination
port;the no monitor session
<session> destination
interface
<interface-number>
command deletes mirror
dentistination port
7.2.3.3 Mirror Port Examples
Port configuration Examples
Command Explanation
Port mode
monitor session <session> source interface
<interface-list> {rx | tx | both}
no monitor session <session> source interface
<interface-list>
Specify mirror source port,
the no monitor session
<session> source interface
<interface-list> command
deletes mirror source port
