b.
Connect the USB cable to the cable connector on the accessory (1), and then connect the grounding
connector to the grounding strip on the accessory, if applicable (2).
2
1
NOTE:
The connectors shown are for a proximity card reader. The cable connector for your
accessory might be slightly different, and might not include a ground connector.
c.
Align the pegs on the underside of the accessory with the connectors in the HIP and insert the
accessory into the HIP.
4.
Connect the power cable, and then press the Power button to turn on the product.
90
Chapter 3 Care and maintenance
ENWW
