HP Digital Sender Flow 8500 fn2 Document Capture Workstation - Manual (Page 115)

3. On the Device Information page, the default product name is in the Device Name field. You can change this
name to uniquely identify this product.
NOTE: Completing the other fields on this page is optional.
4. Click Apply to save the changes.
Manually configure IPv4 TCP/IP parameters from the control panel
Use the control-panel Settings menus to manually set an IPv4 address, subnet mask, and default gateway.
1. From the Home screen on the product control panel, select Settings .
2. Open the following menus:
● Networking
● Ethernet
● TCP/IP
● IPV 4 Settings
● Config Method
3. Select the Manual option, and then select OK .
4. Open the Manual Settings menu.
5. Select the IP Address , Subnet Mask , or Default Gateway option.
6. Select the first field to open a keypad. Enter the correct digits for the field, and then select OK .
Repeat the process for each field to be configured.
Manually configure IPv6 TCP/IP parameters from the control panel
Use the control-panel Settings menus to manually set an IPv6 address.
1. From the Home screen on the product control panel, select Settings .
2. To enable manual configuration, open the following menus:
● Networking
● Ethernet
● TCP/IP
● IPV6 Settings
3. Select Enable , select On , and then select OK .
4. To configure the address, open the Manual Settings menu, and then select Address.
5. Use the keypad to enter the address, and then select OK .
ENWW Configure IP network settings 105
