Check the output-quality settings – HP Digital Sender Flow 8500 fn2 Document Capture Workstation User Manual
Page 138
1.
From the Home screen on the product control panel, select
Scan
.
2.
Select one of the following Scan features:
●
Scan to E-mail
●
Fax
●
Scan to Network Folder
●
Scan to USB Drive
●
Scan to SharePoint®
3.
Select
Options
, and then select
Optimize Text/Picture
.
4.
Select one of the predefined options.
5.
Select
Send
or
Save
to start the scan.
NOTE:
These settings are temporary. After you have finished the job, the product returns to the default
settings.
Check the output-quality settings
This setting adjusts the level of compression when saving the file. For the highest quality, select the highest
setting.
1.
From the Home screen on the product control panel, select
Scan
.
2.
Select one of the following Scan features:
●
Scan to Email
●
Fax
●
Scan to Network Folder
●
Scan to USB Drive
●
Scan to SharePoint®
3.
Select
Options
, and then select
File Type and Resolution
.
4.
Select one of the predefined
Quality and File Size
options, and then select
Done
.
5.
Select
Send
or
Save
to start the scan.
Clean the pickup rollers and separation pad in the Automatic Document Feeder (ADF)
Follow these steps if the ADF does not pick up pages correctly or produces skewed output.
