Page 136
3.
Clean the scanner glass and the document feeder
strips with a soft cloth or sponge that has been
moistened with nonabrasive glass cleaner.
CAUTION:
Do not use abrasives, acetone,
benzene, ammonia, ethyl alcohol, or carbon
tetrachloride on any part of the product; these can
damage the product. Do not place liquids directly
on the glass or platen. They might seep and
damage the product.
NOTE:
If you are having trouble with streaks on
copies when you are using the document feeder,
be sure to clean the small strip of glass on the left
side of the scanner.
4.
Dry the glass and white plastic parts with a
chamois or a cellulose sponge to prevent spotting.
5.
Connect the power cable to an outlet, and then
press the Power button to turn on the scanner.
Check the resolution settings
NOTE:
Setting the resolution to a high value increases the file size and the scan time.
Follow these steps to adjust the resolution setting:
1.
From the Home screen on the product control panel, select
Scan
.
2.
Select one of the following Scan features:
●
Scan to Email
●
Fax
●
Scan to Network Folder
●
Scan to USB Drive
●
Scan to SharePoint®
3.
Select
Options
, and then select
File Type and Resolution
or
Resolution
.
4.
Select one of the predefined
Resolution
options, and then select
Done
.
5.
Select
Send
or
Save
to start the scan.
Check the color settings
Follow these steps to adjust the color setting:
1.
From the Home screen on the product control panel, select
Scan
.
2.
Select one of the following Scan features:
●
Fax
●
Scan to E-mail
126 Chapter 5 Solve problems
ENWW
