Replace parts
Replacing parts when necessary helps ensure high-quality scans. Parts might need to be replaced when
indicated by the Embedded Web Server or control panel, or if the scanner is not working correctly. The HP Digital
Sender Flow 8500 fn2 Document Capture Workstation and HP ScanJet Enterprise Flow N9120 fn2 Document
Scanner ADF Roller Replacement Kit includes the following replacement parts:
● Roller cover
● Separation rollers
● Pickup roller module
The replacement kit also includes detailed instructions for replacing each of these parts.
Replace the separation rollers and cover
NOTE: The HP ScanJet Enterprise Flow N9120 fn2 Document Scanner is shown in this procedure, however, the
instructions are also correct for the HP Digital Sender Flow 8500 fn2 Document Capture Workstation.
Replace the separation rollers under the following conditions:
● Windows: When the Maintenance Recommended dialog indicates they are due for maintenance.
● If the scanner experiences repeated document jams.
NOTE: The roller replacement kit is a consumable and is not covered under warranty or standard service
agreements.
To replace the separation rollers, follow these steps:
1. Press the Power button to turn off the scanner, and then disconnect the USB cable and power supply from
the scanner.
