Step two: Set up Scan to Network Folder
Method one: Use the Scan to Network Folder Wizard
This option opens the setup wizard that is in the HP Embedded Web Server (EWS) for the product. The setup
wizard includes the options for basic configuration.
NOTE: Before you begin: To display the product's IP address or host name, select the Information icon, and
then select the Network icon on the product's control panel.
1. Using the EWS top navigation tabs, click Scan/Digital Send tab.
2. In the left-navigation pane, click Email and Scan to Network Folder Quick Setup Wizards.
3. Click the Save to Network Folder Quick Set Wizard link.
4. On the Add or Remove a Save to Network Folder Quick Set dialog, click Add.
NOTE: Quick Sets are short-cut jobs that can be accessed on the product Home screen or within the Quick
Sets application.
NOTE: The Save to Network Folder feature can be minimally configured without creating a quick set.
However, without the quick set, users must enter the destination folder information at the control panel for
each scan job. A quick set is required to include Save to Network Folder metadata.
5. On the Add Folder Quick Set dialog, complete the following information:
a. In the Quick Set Title field, type a title.
NOTE: Name the Quick Set something that users can understand quickly (e.g., "Scan and save to a
folder").
b. In the Quick Set Description field, type a description explaining what the Quick Set will save.
c. Click Next.
6. On the Configure Destination Folder dialog, complete the following information:
